5SCM管狀保險絲
- 2022-06-21 17:40:14
- 0
廠家長期供應引線汽車保險絲座、保險絲、汽車保險絲座、汽車保險絲盒、保險絲座、汽車保險絲座、玻璃保險絲等
Time-Lag Ceramic Tube Fuse Series (φ5*20MM)
+Approvals(5GE)
UL 100mA-15A
CSA Certified 100mA-12A
CSA Accetpance 12.1~15A
PSE 1A-15A
+Interrupting Ratings
100mA-10A:10,000 amperes at 125v AC
100mA-1A:35 amperes at 250V AC
1.25A-3.5A:100 amperes at 250v AC
3.75A-10A:100 amperes at 250V AC
10.1A-15A:750 amperes at 250V AC
Electrical Characteristics
| Rated Current | 1 In | 1.35 In | 2 In | |
| MIN | MAX | MIN | MAX | |
| 100mA~20A | 4hr | 1hr | 3sec | 120sec |
+Operating Temperature -55℃ to +125℃
| Cartidge Catalog Number | Ampere Rating | Voltage Rating | Nominal Resistance | Nominal Ting L2f |
| (In) | (V) | Cold Ohms | A.Sec | |
| 5SCM.100 | 100mA |
125V
250V |
11.160 | 0.0400 |
| 5SCM.125 | 125mA | 7.8250 | 0.0703 | |
| 5SCM.150 | 150mA | 4.6160 | 0.0832 | |
| 5SCM.160 | 160mA | 4.5000 | 0.0896 | |
| 5SCM.175 | 175mA | 3.9200 | 0.0367 | |
| 5SCM.200 | 200mA | 3.5400 | 0.1400 | |
| 5SCM.250 | 250mA | 2.0150 | 0.2180 | |
| 5SCM.300 | 300mA | 1.8920 | 0.2700 | |
| 5SCM.350 | 350mA | 1.2320 | 0.7350 | |
| 5SCM.400 | 400mA | 0.9350 | 0.9600 | |
| 5SCM.500 | 500mA | 0.6430 | 0.1250 | |
| 5SCM.600 | 600mA | 0.4620 | 0.4005 | |
| 5SCM.700 | 700mA | 0.3200 | 0.3920 | |
| 5SCM.800 | 800mAA | 0.2400 | 0.6400 | |
| 5SCM 001 | 1A | 0.1670 | 1.0000 | |
| 5SCM 1.25 | 1.25A | 0.1050 | 1.5625 | |
| 5SCM 1.50 | 1.5A | 0.0899 | 2.2500 | |
| 5SCM 1.60 | 1.6A | 0.0830 | 2.5600 | |
| 5SCM 002 | 2A | 0.0590 | 6.0000 | |
| 5SCM 2.50 | 2.5A | 0.0780 | 9.3750 | |
| 5SCM 003 | 3A | 0.0665 | 13.500 | |
| 5SCM 3.15 | 3.15A | 0.0600 | 14.884 | |
| 5SCM 004 | 4A | 0.0400 | 32.000 | |
| 5SCM 005 | 5A | 0.0350 | 50.000 | |
| 5SCM 006 | 6A | 0.0280 | 90.000 | |
| 5SCM 6.30 | 6.3A | 0.0220 | 99.225 | |
| 5SCM 007 | 7A | 0.0180 | 122.50 | |
| 5SCM 008 | 8A | 0.0110 | 160.00 | |
| 5SCM 010 | 10A | 0.0080 | 250.00 | |
| 5SCM 012 | 12A | 0.0062 | 432.00 | |
| 5SCM 015 | 15A | 0.0042 | 675.00 | |
| 5SCM 020 | 20A | 0.0027 | 1200.0 |
