5SLM管狀保險絲
- 2022-12-30 18:48:43
- 0
玻璃保險絲| Glass FUSE
插件| DIP
型號 | model: 5.0*20MM
Time-Lag Glass Tube Fuse Series (φ5*20MM)
+Approvals(5GE)
UL 100mA-8A
CSA Certified 100mA-8A
PSE 1A-8A
+Interrupting Ratings
100mA-8A:10,000 amperes at 125v AC
100mA-1A:35 amperes at 250V AC
1.5A-3.5A:100 amperes at 250v AC
3.75-8A:200 amperes at 250V AC
Electrical Characteristics
| Rated Current | 1 In | 1.35 In | 2 In | |
| MIN | MAX | MIN | MAX | |
| 100mA~20A | 4hr | 1hr | 3sec | 120sec |
+Operating Temperature -55℃ to +125℃
| Cartidge Catalog Number | Ampere Rating | Voltage Rating | Nominal Resistance | Nominal Ting L2f |
| (In) | (V) | Cold Ohms | A.Sec | |
| 5SLM.100 | 100mA |
125V
|
11.1600 | 0.04000 |
| 5SLM.125 | 125mA | 7.82500 | 0.07030 | |
| 5SLM.150 | 150mA | 6.05000 | 0.08320 | |
| 5SLM.160 | 200mA | 5.64000 | 0.08960 | |
| 5SLM.175 | 250mA | 4.1300 | 0.03670 | |
| 5SLM.200 | 300mA | 3.10500 | 0.14000 | |
| 5SLM.250 | 315mA | 2.20000 | 0.21800 | |
| 5SLM.300 | 350mA | 2.09200 | 0.27000 | |
| 5SLM.350 | 400mA | 1.14700 | 0.73500 | |
| 5SLM.400 | 500mA | 0.88500 | 0.09600 | |
| 5SLM.500 | 600mA | 0.64900 | 1.37500 | |
| 5SLM.600 | 630mA | 0.47500 | 2.52000 | |
| 5SLM.630 | 700mA | 0.40800 | 2.77800 | |
| 5SLM.700 | 750mA | 0.33700 | 3.43000 | |
| 5SLM.750 | 800mA | 0.29800 | 3.75300 | |
| 5SLM.800 | 1A | 0.26000 | 4.48000 | |
| 5SLM 001 | 1.25A | 0.18750 | 7.00000 | |
| 5SLM 1.25 | 1.5A | 0.14700 | 12.5000 | |
| 5SLM 1.50 | 1.6A | 0.11500 | 18.0000 | |
| 5SLM 1.60 | 2A | 0.10580 | 20.4800 | |
| 5SLM 002 | 2.5A | 0.06750 | 40.0000 | |
| 5SLM 2.50 | 3A | 0.05250 | 62.5000 | |
| 5SLM 003 | 3.15A | 0.04870 | 81.0000 | |
| 5SLM 3.15 | 3.5A | 0.04470 | 99.2250 | |
| 5SLM 3.50 | 4A | 0.03800 | 122.500 | |
| 5SLM 004 | 5A | 0.03310 | 152.000 | |
| 5SLM 005 | 6A | 0.02030 | 212.500 | |
| 5SLM 006 | 6.3A | 0.01630 | 396.000 | |
| 5SLM 6.30 | 7A | 0.01380 | 436.000 | |
| 5SLM 007 | 7.5A | 0.01350 | 588.000 | |
| 5SLM 7.50 | 8A | 0.01220 | 365.625 | |
| 5SLM 008 | 10A | 0.01100 | 414.000 | |
| 5SLM 010 | 12A | 0.00860 | 650.000 | |
| 5SLM 012 | 13A | 0.00780 | 1296.00 | |
| 5SLM 015 | 15A | 0.00530 | 2025.00 | |
| 5SLM 020 | 20A | 0.00290 | 3600.00 |
